NE200/300 Series Drive User Manual
122 Chapter 6 Parameter description
not be stopped instantly while the CCI current is Ib.
Note: fa is defined as ‘Threshold value of Zero Freq. running’ (F2.33),
fb-fa is defined as ‘Range between start Freq. and threshold value of
Zero Freq’ (F2.34).
These function codes are used to avoid the start-stop of drive continually,
used to realize the stand-by and sleep-mode.
Fig. 6-7
6.4 Vector Control Parameters (F3)
F3.00 Speed loop proportional gain
1
Range: 1~3000【1000】
F3.01 Speed loop integral time 1 Range: 1~3000【300】
F3.02 Switching frequency 1 Range: 0.0～60.00Hz【5.00Hz】
F3.03 Speed loop proportional gain
2
Range: 1~3000【800】
