NE200/300 Series Drive User Manual
150 Chapter 6 Parameter description
F6.32 Pos. and Neg. logic terminal X 1
Range: 【0000】
Units: Logic of X1 terminal
Tens: Logic of X2 terminal
Hundreds: Logic of X3
terminal
Thousands: Logic of X4
terminal
F6.33
② Pos. and Neg. logic terminal X 2
Range: 【0000】
Units: Logic of X5 terminal
Tens: Logic of AI1 terminal
Hundreds: Logic of AI2
terminal
F6.33
③ Pos. and Neg. logic terminal X 2
Range: 【0000】
Units: Logic of X5 terminal
Tens: Logic of X6 terminal
Hundreds: Logic of X7
terminal
Thousands: Logic of X8
terminal
Notes:
1) Terminal 24、25、26、27、42、43、44 and 49 are not impacted by F6.33.
2) Pos. logic of Xi terminal: Be valid while connecting between Xi and
COM.
3) Neg. logic of Xi terminal: Be valid while disconnecting between Xi and
COM.
6.8 Output terminals group (F7)
② F7.00 Reserved
③ F7.00 DO terminal output definition
Range:0~31【0】
F7.01 Y1 terminal output selection Range: 0～31【1】
② F7.02 Reserved
