NE200/300 Series Drive User Manual
Chapter 6 Parameter description 141
Value
Function Description
0 NULL
This is to define invalidity of the terminal. The
drive shall have no action even there is pulse
input. The undefined terminals can be set
into NULL to avoid mistaken action.
1 Forward (FWD) Control the forward rotation and
reverse rotation of the drive via the external
terminals
2 Reverse (REV)
3 RUN
Control the drive running via the external
terminal.
4 F/R running direction
Control the direction of the drive. inactive
state: Forward; Active state: Reverse
rotation.
5 HLD self-hold selection
Running signal self-hold terminal, refer to
F6.00 terminal command modes setup.
6
Forward rotation Jog
(FJOG)
Terminals JOG running. FJOG is prior. For
details regarding frequency and Jog
acceleration/deceleration time during the Jog
running, refer to F2.00, F2.01 and F2.02
function codes.
7
Reverse rotation Jog
(RJOG)
8 RESET (RST)
The terminal defined as RST can be used to
do fault reset under fault status; In running
status, activating this terminal will stop the
drive according to preset stop mode.
9
Frequency source
switching
When the frequency reference selection
(F0.05) is set to 3, this terminal is used to
switch Freq. reference1 and Freq.
reference2. When the frequency source
selection (F0.05) is set to 4, it performs
switching between frequency ref. 1 and
(freq. ref.1 + freq. ref.2)
10 Terminal UP When the frequency is given by the external
terminals, it is used to modify increment and
decrement commands of frequency. When
the frequency source is set to digital setup, it
can be used to adjust up & down the setup
frequency.
11 Terminal DOWN
12 UP/DOWN setup clear When the frequency reference is digital
