NE200/300 Series Drive User Manual
Chapter 6 Parameter description 163
F8.11 PID parameters switching Range: 0～2【0】
0: No switching, use the first group parameters
1: Switching by terminal，to defined the multi-function terminals to switch
two groups of PID parameters.
2: Auto-switching by deviation，Refer to the F8.12, F8.13 instructions.
F8.12 PID para. switching Deviation
1
Range: 0.0～999.9【20.0】
F8.13 PID para. switching Deviation
2
Range: 0.0～999.9【80.0】
Two groups of PID parameters can be switched by feedback deviation
from the preset PID value. It is shown in figure 6-23 as below.
Figure 6-23 PID parameters switching
F8.14 PID delay time constant Range: 0.00～100.0s【0.0s】
The PID control frequency output delay time setting.
F8.15 Deviation limit Range: 0.0～999.9s【0.2】
When the deviation of feedback value from preset value lies within the
deviation limit range, PID regulator stops adjustment. The proper settings of
