NE200/300 Series Drive User Manual
Chapter 6 Parameter description 181
This parameter is used to define the STOP key functions, including stop
and fault reset.
0: Active only in the keypad control mode
1: STOP key stop function active in the terminal/communication control
mode
2: STOP key fault reset function active in the terminal/ communication
control mode
3: STOP key stop and fault reset function active in the terminal/
communication control mode
FE.03 Running freq. (Hz)
(before compensation)
Range: 0~3【2】
FE.04 Running freq. (Hz)
(after compensation)
Range: 0~3【0】
FE.05 Reference frequency (Hz,
blinking)
Range: 0~3【1】
FE.06 Output current(A) Range: 0~3【2】
FE.07 Bus voltage (V) Range: 0~3【3】
FE.08 Output voltage (V) Range: 0~3【0】
FE.09 Output torque (%) Range: 0~3【0】
FE.10 Reference torque (%, blinking) Range: 0~3【0】
FE.11 Rotate speed (r/min) Range: 0~3【0】
FE.12 Reference speed (r/min blinking)
Range: 0~3【0】
FE.13 Output power (kW) Range: 0~3【0】
FE.14 AI1 (V) Range: 0~3【0】
FE.15 AI2(V) Range: 0~3【0】
FE.16 Analog PID feedback Range: 0~3【0】
FE.17 Analog PID setup Range: 0~3【0】
FE.18 Terminal status (no unit) Range: 0~3【0】
FE.19 Actual length Range: 0~3【0】
FE.20 Reference length Range: 0~3【0】
FE.21 Linear speed (m/s) Range: 0~3【0】
