NE200/300 Series Drive User Manual
Appendix C: Extension cards Instruction 221
Option card
Model No. Terminals
Function Models Range
Resolver PG
encoder
option
B602PG03A
----------------
0303A001
R1，R2 Base time signal
NE300
S1，S3 SIN+ and SIN- input signal
S2，S4
COS+ and COS- input
signal
GND
Ref. GND of the
differential signal, can
wiring the shield line
AO+，AO-
The input encoder signal
is outputted as A/B/Z
differential signal, the
location signal, though the
IC operation. Terminal to
Terminal
BO+，BO-
ZO+，ZO-
5V differential
signal PG
encoder
option
B602PG04A
303A000
+5V, COM
Power supply
NE300
A+，A-
A/B/Z input of the 5V
differential signal
B+，B-
Z+，Z-
U+，U-
The UVW location signal
of encoder
V+，V-
W+，W-
B+, B-
24V
differential
signal PG
encoder
option
B602PG02A
----------------
0303A005
+24V,
COM
Power supply
NE300
A+, A-
A/B signal input
B+, B-
Note:
1)
When using ±10V Option card, the AI1 on control board is invalid.
2)
The work voltage of the Resolver PG encoder is 7V.
3)
The work voltage of the 5V differential signal encoder is 5V. UVW also is used as the
normal encoder.
4)
The work voltage of the 24V differential signal encoder is 24V.
