I. Part Names
F
.S.
ND8
N
CB
0
.
4
0.2
0.
8
0
.
6
JA
PA
N
A
chr
0.
90
0
B
I
N
O
P
H
OT
O
P
H
O
T
O
B
IN
O
&
Condenser centering
screws
Condenser aperture
diaphragm ring
Bertrand lens turret
Bertrand lens focus ring
Swing-out lever for the
condenser top lens
Slot (20 x 6 mm)
Used for parts available on the market
such as a compensator or so on.
Objective centering screws
Field lens
Lamp cable
Field diaphragm control
Filter selector switches
Fine focus knob
Coarse focus knob
Coarse focus stopper ring
(CLAMP)
Optical path selector lever
Analyzer slider
Bertrand lens centering screws (both sides)
Photomicrographic equipment clamp screw
Diopter
adjustment
ring
Eyepiece
