Nikon ECLIPSE Ni-E User Manual

Chapter 1 Components
5
Components
ND
ERGO/JOY
DSC2
DIA SHUTTER
STAGE
EX
1.4
Connectors
MODEL ECLIPSE Ni-E
NIKON CORPORATION
TOKYO, JAPAN
MADE IN JAPAN
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est confirme à la norme NMB-003 du Canada.
910001
CONTACT ARM2
DSC1
HGFIE
BOX
USB
EPI SHUTTER
1.
2.
3.
Do not touch the lamphouse while the lamp is lit.
The surface of the lamphouse becomes hot when the
lamp is on.
Turn off the power and allow the lamp and lamohouse
to cool enough before replacing the lamp.
Wait for at least 30 minutes after turning off the
lamp.
Use 12V100W HALOGEN lamp only.
HALOGEN 12V100W
952001
NI-LH
CAUTION!
-High Temperature-
JAPAN
Ni-E main body (Rear)
Ni-E CONTACT
ARM1
LAMP
FASTENING
POSITION SW
OFF ON
100-240V~ 5A 50/60Hz
MODEL NI-CTLA
MADE IN JAPAN
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following
two conditions:
(1) this device may not cause
harmful interference, and
(2) this device must accept any
interference received,
including interference that
may cause undesired
operation.
This Class A digital apparatus
complies with Canadian ICES-003.
Cet appareil numérique de la
classe A est confirme à la
norme NMB-003 du Canada.
540001
Control Box A (Front/Rear)
CONTACT ARM1
(Connect to CONTACT ARM1 o
f
control box A)
EPI SHUTTER
(Connect to EPI motorized
shutter)
CONTACT ARM2
(Connect to CONTACT ARM2 o
f
Ni-E main body)
CONTACT ARM2
(Connect to CONTACT ARM2 o
f
contact arm)
USB
(Connect to DS-L3 or PC)
DSC1
(Connect to EXT.I/O of
DS-L3/U3)
HGFIE
(Connect to motorized HG
precentered fibe
r
ill
u
min
a
t
o
r
)
BOX
(Connect to Ni-E of control box A)
DSC2
(Connect to EXT.I/O o
f
DS-L3/U3)
ERGO/JOY
(Connect to ergo controlle
r
o
r
joystick controller)
ND
(Connect to the motorized
ND filter wheel)
EX
(Connect to motorized
excitation wheel)
STAGE
(Connect to motorized
XY stage controller)
DIA SHUTTER
(Connect to DIA
motorized shutter)
CONTACT ARM1
(Connect to CONTACT ARM1
of contact arm)
LAMP
(Connect to dia-illumination
lamphouse)
A
C inlet
(Connect to AC power using a
power cord)
Fastening position mode switch
(ON: fastening position mode,
OFF: normal mode)
Input voltage display label
Ni-E (Connect to BOX of Ni-E main body)
Power LEDPower switch
