Chapter 2 Microscopy Operations
22
Bright/Dark-field
Microscopy
Preparation
Focus and Optical
System Adjustment
Micro-
scopy
Bright/Dark-field
Microscopy
123456 7 8 9 10 11 12 13 14 15 16 17 18 19
6
Set the condenser turret to the [OPEN] (empty: bright-field) position.
Press the FUNCTION button 1/2 to turn the condenser
turret and display [OPEN] on the front panel of Ni-E. The
turret's empty position enters the optical path in this
state.
Button 1 is for counterclockwise rotation and button 2 is
for clockwise rotation.
IN
ND
8
ND
32
NCB
11
OUT
Moving the condenser to the empty position
PA__2x____Z:_____0.000um
OPEN__AS30.0mm__FS30.0mm
[CONDEN.] button, sub screen: [OPEN]
Optical module
in optical path
[OPEN]
To Next Page
