Nikon ECLIPSE Ni-E User Manual

Chapter 2 Microscopy Operations
52
Differential
Interference Contrast
Microscopy
Preparation
Focus and Optical
System Adjustment
Microscopy
Differential Interference
Contrast Microscopy
12345 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 ■ ■
5
Fully open the field diaphragm and aperture diaphragm.
Press the left side ( mark side) of the DIA field
diaphragm and DIA aperture diaphragm button.
Pressing the right side (
mark side) of both buttons will
close the diaphragm.
ND
8
ND
32
OUT
IN
NCB
11
Fully opening the field and aperture diaphragms
PA__2x____Z:_____0.000um
OPEN__AS30.6mm__FS30.6mm
[F. STOP] button,
sub screen: DIA field diaphragm open
[A. STOP] button, sub screen: DIA aperture
diaphragm open
DIA aperture
diaphra
g
m button
DIA field diaphragm
button
