Dimensional drawing VPM 240
T
he dimension drawing shown is for a left version.
All measurements are in mm.
750
152
Ø400
365
549
326
719 428
80
2155
1240
100
1200
100
565
Supply air
Extract air
Outdoor air
Discharge air
VPM 120-560 (English)
BY NILAN
11
