Dimensional drawing VPM 360
T
he dimension drawing shown is for a left version.
All measurements are in mm.
939
152
Ø500
405
629
366
799 510
125
2255
1400100
1200
100
565
Supply air
Extract air
Outdoor
air
Discharge
air
12
