Dimensional drawing VPM 120
T
he dimension drawing shown is for a left version.
All measurements are in mm.
1975
990100
1000
100
516
591 312
76
675
152
Ø315
302
424
264
Supply air
Extract air
Outdoor air
Discharge air
10
