Control System 28Service Manual – SC3000
Black-box: Record of Alarms, Battery Management Parameters (see page 32
- 33), Partial Hour Counter (continued)
Example 1:
Last stored alarm: alarm G8 occurred when the machine working hours were 24h and 19m, next to last stored
alarm: alarm F4 occurred when the machine working hours were 22h and 5m.
Logged alarm-1:
ALL
_
G8: 24h,19m
PROGRAMMER
Logged alarm-2:
ALL
_
F4: 22h,55m
PROGRAMMERPROGRAMMER
P100399
Example 2:
Charging cycle interrupted before completion when the machine working hours were 15h and 45m (last stored
event).
GC (-1) 15h,45m
21hours, 31 min
PROGRAMMER
Charging cycle time when interrupted
P100400
