Recovery System 55Service Manual – SC3000
Component Location
• Recovery tank
• Recovery tank cover
• Gasket cover
• Container with debris collection grid
• Float ball and cage
• Vacuum system motor (M2)
• Squeegee vacuum hose
• Recovery water drain hose
• Vacuum system wiring harness connection
• Function electronic board (EB1)
2
3
7
1
8
Recovery tank cover
Gasket cover
Container with
debris collection grid
Recovery tank
Float ball and cage
P100559
6
4
5
Vacuum system
motor (M2)
Squeegee vacuum
hose
Recovery water drain
hose
P100560
Vacuum system
wiring harness
connection
Function electronic
board (EB1)
P100560b
