Scrub System, Cylindrical 78Service Manual – SC3000
Specications
Description
Nilsk BR 752C
Cleaning width
28 in (710 mm)
Cylindrical brush size (diameter x length)
5.7 x 27.2 in (145 x 690 mm)
Deck right/left offset
3.5 / 3.5 in (90 / 90 mm)
Cylindrical brush deck distance from the oor (when lifted)
0.8 in (22 mm)
Brush electromagnetic switch
24V 70A
Cylindrical brush motor technical data
2 x 0.8 hp (2 x 600 W 24V)
1800 rpm
Actuator technical data
Maximum load
700 N
Maximum speed
16 mm/s
Voltage
24V
Protection class
IP 65
Cylindrical brush speed
720 rpm
Cylindrical brush pressure
77.1 lb (35 kg)
