Scrub System, Disc 93Service Manual – SC3000
Specications
Description
Nilsk BR 652
Advance SC3000
Nilsk BR 752
Cleaning width 26 in (660 mm) 28 in (710 mm)
Brush/pad diameter 13 in (330 mm) 14 in (355 mm)
Deck right/left offset (variable)
0 ÷ 3.9 in / 1 ÷ 0 in
(0 ÷ 100 mm / 25 ÷ 0 mm)
0.6 ÷ 5.9 in / 4.1÷ 0 in
(15 ÷ 150 mm / 105 ÷ 0 mm)
Brush distance from the oor (when lifted) 1.9 in (48 mm) 1.9 in (48 mm)
Brush/pad-holder motor power 2 x 0.53 hp (2 x 400 W)
Actuator technical data
Maximum load
700 N
Maximum speed
16 mm/s
Voltage
24V
Protection class
IP 65
Gas spring technical data
Stroke
50 mm
Strength
180 N
Brush/pad-holder speed 230 rpm
Brush/pad-holder pressure with extra-pressure function turned off 66.1 lb (30 kg) 70.5 lb (32 kg)
Brush/pad-holder pressure with extra-pressure function turned on 105.8 lb (48 kg) 110.2 lb (50 kg)
