Electrical System 48Service Manual – SC3000
Delta-Q IC 650 Charge Prole Selection
Set the DELTA-Q on-board charger according to the type of batteries installed as shown below:
7. Disconnect AC input (A) from the charger, or from the wall outlet. Wait 30 seconds for the input relay to
open.
D
E
FC
P100396
8. While reconnecting AC input (B), press and hold the
Select Charge Prole Button (C). Hold the button until
Error Indicator (D) is on and Amber in color and Battery
Charging Indicator (E) starts ashing Green.
Note: You will have to hold the button for 15-
20 seconds for this to occur.
9. Press and release the Select Charge Prole Button (C) to
advance through charging proles loaded on the charger.
The selected charging prole will be displayed (F) up to
three times (e.g. “P-0-1-1” for Prole 11).
Note: See the BATTERY CHARGER PROFILE
SELECTION CHART in the next page
for the relevant prole. Process will time
out and prole will remain unchanged if
there is 15 seconds of inactivity, a prole
number is allowed to display three times,
or if AC power is cycled.
10. Once desired charging prole is displayed, press and hold
button (C) for 10 seconds to conrm selection and exit
Prole Selection Mode.
Note: Make sure both the Error Indicator and
the Battery Charging Indicator are no
longer illuminated before releasing the
button.
11. Press the Select Charge Prole Button (C) to check that
the desired prole is selected.
B
A
To Next Page
