Scub Sytem - Disc 46Service Manual – SC351
Brush Deck Disassembly/Assembly (Continues)
11. Install the centre ange springs (K) by engaging
them on the deck housings and on the centre
ange housings (L) as shown in the gure.
Assembly
12. Assemble the components in the reverse order of
disassembly and note the following:
◦ Couple the tooth (M) of the end-of-stroke
spacer tab (N) and the deck ange, as shown
in the gure.
◦ Assemble the brush deck by matching the
deck ange polarization (O) with the one of
the deck holder (P).
Note: For further information on deck
components see the Spare Parts
List.
K
P100801
L
P100802
M
N
P100799
O
P
P100803
