81Service Manual – SC401, SCRUBTEC 344 05 - Control System - Cord
Main Machine Controller (EB1) Connectors (continues)
J211 A: JST B2B-EH-A (LF)(SN) (2 ways, vertical)
PIN Description
Controller
in/out
V ref. I max. Connected to
1 Power button output Out 5V <1A UI.J201.8
2 Power button input In 5V <1A UI.J201.7
1 2
1 2
Figure 25:
