Scrub System, Cylindrical 107Service Manual – SC6500
™
3. Use a 1/2” drive extension and
ratchet in the large pulley
slot, to rotate the pulley while
pulling outward on the belt to
roll the belt off of the pulleys.
4. Place the new belt on the
large pulley and then use a
plastic wire tie to hold the belt
on the pulley.
5. Loop the belt over the small
pulley and hold it on.
6. Use a 1/2” drive extension and
ratchet in the large pulley
slot, to rotate the pulley to roll
the belt onto the pulley.
