Sweep System, Side Broom 174Service Manual – SC6500
™
Specifications
Component Specifications
Side Broom Gearnotor
Type – permanent magnet, 36 VDC
Gearbox – 27:1 ratio
Power – 162 Watts
Output – 105 in-lbs. @ 84 RPM
Current – 6 Amps
Side Broom Actuator Motor
Type – permanent magnet, 36 VDC, 1/6 HP, reversible
Motor-to-drive-screw ratio – 21.7:1
Performance Data
No Load – Thrust 0 lbs., Speed 39 ±4 in/min, 1.4 Amps max.
Full Load – Thrust 600 lbs., Speed 30 ±3 in/min, 6.7 ±1 Amps
Start Thrust – 600 lbs.
Shop Measurements
Shop measurements are values that were measured on a real machine. While they are not “specications”,
they can help you recognize normal vs abnormal.
Side Broom Contactor (K6)
Resistance at room temperature: 93 ohms
Side Broom Motor
Current draw for one motor with no load (broom off): 1.5-1.8 Amps
Current draw in use on dry oor: 4.0-4.2 Amps
Side Broom Actuator Motor
• Current draw going up: 2.4 Amps
• Current draw going down: 1.2 Amps
