Nira i7x - Temperature sensors

© 2005-2016 Nira Control AB 79
Pressure sensors for auxiliary engine control or logging purpose
Pressure
Measurement
Name in Nira Rk
Fuel Pressure
Bv Fuel Pressure
Oil Pressure
Bv Oil Pressure
Temperature sensors
Characterize the temperature sensor by entering the correct temperature for
the given resistance.It’s possible to adapt both axis value and table value to
achieve the right sensor curve.
Note: It’s only allowed to edit axis value while you’re offline.
Example of temperature sensor characteristic
Temperature sensors for engine control
Temperature
Measurement
Name in NIRA rk
Coolant
Temperature
Bv Coolant Temperature
MAT
Bv Manifold Air Temperature
Temperature sensor for auxiliary engine control or logging purpose
Temperature
Measurement
Name in NIRA rk
Boost
Temperature
Bv Boost Temperature
Fuel
Temperature
Bv Fuel Temperature
