6 Software Development Kit
The Software Development Kit allows access to registers controlling the laser’s
operating parameters using its Generic User Interface. For general operation it is
recommended to use CONTROL. This section’s purpose is to illustrate how to
use the Generic User Interface to set the laser’s operating parameters. Table 10
presents the registers by their function with a link to a detailed description.
Table 10 Generic user interface registers
Note: For a full description of the SDK, registers and the Generic User Interface,
refer to the NKT Photonics document: SDK Instruction Manual. The manual is in-
stalled when the SDK installer is run.
Function Register Bit# Unit Description Link
Wavelength tuning 0x2A N/A picometers Tuning the wavelength on
page 74
Operating mode selection -
toggle
0x31 9 hex Setting the operating mode on
page 74
Enabling Auto-start - toggle 0x31 11 hex Auto start on page 74
Emission delay control 0x3A N/A seconds Setting the emission delay on
page 75
Narrow and wide range –
toggle
0x31 1 hex Narrow and wide range setting
on page 75Se
Selecting the wavelength
modulation source signal
0x31 5 hex Setting the wavelength
modulation source on page 76
Internal function generator -
toggle
0x31 4 hex Setting the wavelength
modulation signal coupling on
page 77
Function generator
frequency
0xB8 N/A Hz (32 bit) Internal generator frequency on
page 78
Function generator
amplitude
0x2B N/A percent Internal generator amplitude on
page 78
Function generator waveform
type
0xB7 N/A hex Internal generator signal
waveform on page 78
Function generator -
outputting the signal
0x31 6 hex Internal generator -signal output
on page 79
Wavelength modulation -
global enable
0xB5 N/A 0 or 1 Wavelength modulation on/off on
page 80
Trigger pin signal direction -
input or output
0XB4 1 hex Trigger setting input/output on
page 80
Trigger signal indicating or
initiating emission
0xB4 4 hex Trigger indicates emission on
page 81
Trigger set to sawtooth
wavelength modulation
0xB4 2 hex Trigger sawtooth wavelength
modulation on page 81
