Nokia 9500 - Keys and Connectors; Communicator Interface

Keys and connectors
Keys and connectors
1— Power key
.
2—Scroll key, left and right selection keys. Press the
center of the scroll key, or press either selection key to
perform the function shown above it.
3—Call key (on the left,
), End key (on the right,
).
4—PopPort™ connector for the USB data cable,
headset, and loopset.
5—Infrared port and microphone.
6—Charger connector.
7—Earpiece.
8—Loudspeaker for hands-free phone calls and other
audio usage.
Communicator interface
Communicator keyboard
1—Application buttons. Each button starts the
corresponding application, except My own key, which
you can configure to open any application. Press Ctrl
+My own key to select the application you want the My
own key to open.
2—Character key. Opens a character table where you
can select special characters. Press Chr+keys with green
symbols to access characters and functions behind key
combinations.
3—Help key. To get support using your device, press
Chr+
.
4—Bluetooth key. To activate Bluetooth, press the Chr
+
.
13
Getting started
