Nokia Lumia 1320 - Page 143

RM-994/ RM-995/ RM-996
System Module
Page 142 NOKIA INTERNAL USE ONLY
Copyright © 2013 Nokia. All rights reserved.
1
MTP
GND
34
2
GND
GND
33
3
D3+
AVEE
32
4
D3-
AVDD
31
5
GND
GND
30
6
D2+
GND
29
7
D2-
RESET
28
8
GND
TE
27
9
CLK+
BC
26
10
CLK-
GND
25
11
GND
VDDI
24
12
D1+
VDDA
23
13
D1-
GND
22
14
GND
LED1-
21
15
D0+
LED2-
20
16
D0-
LED+
19
17
GND
GND
18
Figure 43 Display flex pin order
