RM-994/ RM-995/ RM-996
System Module
NOKIA INTERNAL USE ONLY Page 145
Copyright © 2013 Nokia. All rights reserved.
Keypad interface
The phone HW supports standard 3 x Windows Phone 8 keypad, side keys (Volume up/down keys, Power/
Lock key and bi-functional Camera key for half and full key press detection), and Back, Home and Search
touch keys on the front.
Figure 46 Keypad diagram
