Nordson 3100V Series Customer Product Manual

Series
3000V
lnput/Output Board
E 1-T
3.
Additional
Features
6. Close and secure
the electrical enclosure. Refer
to Opening
and
Closi ng the Electrical Enclosu
re in lhe
Control
section.
7. Restore
power
to the
unit and resume normal operation
The l/O board
adds the following
additional features that can be
programmed
using the
SYSTEM SETTINGS controls:
o
Auto
Standby Tlmeout
.
ln
Standby Timeout
o
Remote Heaters
On/Remote Pump Enable
.
Rempote Pattern
Select
(Pattern
control
units
only)
Each feature
is factory-set
at
zero
(0),
which means the feature is
disabled. To
program
these features, refer
to
Programming
SYSTEM
SE77INGS Controlsinlhe lnstallation
section. Refer to Table E 1-3 for a
description of how
each feature works
and a
range
of
possible
settings.
Table E 1-3 SYSTEM
SETTINGS Timeout Features
Feature No. Feature
Description
Default
Setting
Optional
Settings
30
Auto
Standby
Timeout
Allows
you
to
program
the unit to automatically
enter
the
standby
mode and maintain
heated
zones at standby
temperature setpoints if
a
gun
is not fired
during the specified
period
of time.
The
unit
will remain
in standby
mode indefinitely
unless a
gun
is fired
or unless a value
other than
zero
(0)
is entered
in Feature
31,
ln
Standby
Timeout.
0
(setting
is off)
0-1440
(minutes)
31 ln
Standby
Timeout
Allows
you
to
program
the unit
to automatically
exit the standby mode
and enter the sleep
mode
(turn
the heaters off) if
a
gun
is not fired during
the specified
period
of time.
0
(setting
is off)
o-1440
(minutes)
34 Remote
Heaters
On/Remote
Pump Enable
Allows
you
to remotely turn heaters
on or to
enable/disable the
pump.
This
feature is only
available on the enhanced l/O
board.
0
(Remote
Heaters
On)
0
(Remote
Heaters
On)
1
(Remote
Pump Enable)
51
Remote
Pattern Select
(Pattern
control units
only)
Allows a
pattern
to be
selected through the
liO
board. lf this feature
is set to 1
or
2,
patterns
can be selected via inputs on
the l/O board.
Refer to Table E 1-4lor
the
various
settings.
This feature is only
available on the enhanced
l/O board.
0
(setting
is off)
1or2
@
2000 Nordson Corporation
All righls reserved
41-3000y
lssued 5/00
El EN-02-[3V-!OJ-3
