MEG® II Airless Spray Guns with 10 ft Cable
© 2021 Nordson Corporation
1602990-12
Installation
WARNING:  
safety instructions in this document and all other related documentation.
WARNING:  󰀨
or aggressive substances that the equipment may be exposed to.
Mounting
See Figure 2.
Mount the MEG II gun on the mounting plate, using the two holes in the manifold base.
• If you are replacing an A10A, A14A, or A20A spray gun, remove it and use the two

mounting plate.
• If your system does not use any of these spray guns, refer to Specications on page
33 for mounting dimensions.
Fluid Connections
NOTE:  




1
2
3
4
5
6
7
8
9
10
Figure 2 
1. Electrical conduit
2. Socket head screws
3. Gun
4. Seat O-ring
5. Nozzle
6. Nozzle nut
7. CO plate plug and O-ring
8. Pressure Transducer plugs and
O-rings
9. Ground cable and clamp
10. Fluid Fittings
