MEG® II Airless Spray Guns with 10 ft Cable
© 2021 Nordson Corporation
1602990-12
Electrical Connections
WARNING: Use a driver/trigger device which meets the electrical requirements listed in
this manual. Using an improper driver/trigger device may result in damage to the gun
and/or driver/trigger device. Contact your Nordson representative for more information.
Special Conditions for Safe Use
SGS
The electrical conduit wire leads must be suitably protected against mechanical damage
and terminated within a terminal or junction box suitable for the conditions of use. The
fuse block and 1 amp fuse must be used as shown below.
Connections
See Figure 3.
1.
2.
WARNING: If using the MEG II gun with solvent-based coating materials, you must
install the fuse and fuse holder to the gun coil circuit. Failure to observe this warning
could result in personal injury or property damage.
3. If using the MEG II gun with solvent-based coating materials, install the fuse holder
and 1 amp fuse shipped with the spray gun on the terminal block and connect one of
the black coil wires to the fuse holder.
4.
WARNING: The MEG II gun must be connected to a true earth ground. Use the supplied
ground cable and clamp and test the connection for continuity before putting the gun into
service.
5.
ground.
