33
MEG® II Airless Spray Guns with 10 ft Cable
© 2021 Nordson Corporation
1602990-12
Specications
Item Specication
Dimensions See Figure 12 and Figure 13.
Electrical Requirements 48 Vdc, 3 amps for 3 msec and 1 amp holding
Fluid Pressure
Fluid Temperature
Nozzle Flow Rate
pH Viscosity
6.5-8.5
Weight
II
2 G
Conduit and
Cable Length:
10 ft (304 mm)
1.06 in
27 mm
3.87 in.
98 mm
4.87 in.
124 mm
5.75 in.
146 mm
0.80 in.
20 mm
0.37 in.
9 mm
1.54 in.
39 mm
1.28 in.
32 mm
1.85 in.
47 mm
Mounting Holes
Figure 12 Gun Dimensions for Reduced Cavity Spray Guns
