Nordson MEG II - Ball and Seat Service Kit; Body with Coil Service Kit

25
MEG® II Airless Spray Guns with 10 ft Cable
© 2021 Nordson Corporation
1602990-12
Ball and Seat Service Kit
See Figure 7 and Figure 8.
Item Part Description Quantity Note
— 1062095 SERVICE KIT, ball and seat, MEG II, reduced cavity 1 A
— 1613309 SERVICE KIT, ball and seat, MEG II, reduced cavity, FFKM 1 A
— 1076115 SERVICE KIT, ball and seat, MEG II, extended tip 1 B
3
945067 • O-RING, EPR, 0.375 x 0.50 x 0.063 in. 1 C
1614045 • O-RING, FFKM, 0.375 x 0.50 x 0.063 in. 1 C
4 - - - - - - • SEAT, MEG 1
5
339047 • O-RING, EPR, 0.375 x 0.875 x 0.063 in. 1
1614046 • O-RING, FFKM, 0.750 x 0.875 x 0.063 in. C
6 - - - - - - • ARMATURE ASSEMBLY, MEG II 1
7 237399 • SPACER 1
NOTE: A. See Figure 7.
B. See Figure 8.
C. This O-ring is not used with the Extended Tip Service Kit, part 1602883.
Body with Coil Service Kit
See Figure 7 and Figure 8.
Item Part Description Quantity Note
— 343993 SERVICE KIT, body with coil, MEG II 1
— 1613311 SERVICE KIT, body with coil, MEG II, FFKM 1
3
945067 • O-RING, EPR, 0.375 x 0.500 x 0.063 in. 1 A
1614045 • O-RING, FFKM, 0.375 x 0.50 x 0.063 in. 1 A
5
339047 • O-RING, EPR, 0.375 x 0.875 x 0.063 in. 1
1614046 • O-RING, FFKM, 0.750 x 0.875 x 0.063 in. 1 A
9 - - - - - - • BODY, MEG II 1
10
940176 • O-RING, EPR, 0.688 x 0.813 x 0.063 in. 1
1614047 • O-RING, FFKM, 0.688 x 0.813 x 0.063 in. 1 A
NOTE: A. This O-ring is not used with the Extended Tip Service Kit, part 1602883.
