MEG® II Airless Spray Guns with 10 ft Cable

1602990-12

Wire Color Function

Black Coil

Green/Yellow Ground

Black

Grn/Yel

Black

Grn/Yel

Figure 3 Electrical Connections

1. iTrax

spray controller (or NC-1



2. Customer-supplied wires

3. Customer-supplied terminal block

4. Fuse holder and 1 amp fuse



5. Customer-supplied junction box

6. Lock nut

7. Seal ring

8. Meg II Gun

9. Ground cable

Nozzle and CleanSleeve

Cover

See Figure 2.

1. 

2. 

NOTE:  An alternate PTFE O-ring kit is included with the spray gun to replace the

standard seat O-ring for certain applications.

3. 

4. 



5. 

procedure as detailed in the CleanSleeve Cover
