Point Programming
3URJUDP &KDQJH
AFP-300/AFP-400 Programming PN 50259:C1 06/19/97 11
7\SH &RGHV IRU 0RQLWRU
0RGXOHV 00;
Table 11 lists Monitor Module (MMX) Type Codes:
Table 11 Monitor Module (MMX) Type Codes
Type Code Label Special Function
Monitor none (default)
Pull Station none
Smoke Detect none
Heat Detect Use to monitor conventional detectors
Blank (12 spaces) none (use when no other Type Code applies)
Waterflow causes a non-silenceable alarm
Supervisory becomes a supervisory point
Tamper becomes a supervisory point
Non Fire special non-alarm point
Hazard Alert special non-alarm point
Fire Control special non-alarm point
Abort Switch aborts the release zone
Man. Release overrides Abort
Silence functions like the Silence switch
System Reset functions like the Reset switch
Evacuate functions like the Alarm Activate switch
PAS Inhibit overrides Presignal
Trouble Mon short = trouble
Burglar Ala causes a Security alarm on an open or short
Tele. Page allows remote paging to a fire area
AllCall Page allows All Call paging from a remote phone in the
installation
Man Rel Delay initiate manual release with 10-second delay
Second Shot reactivate release output, second agent discharge
Sprinklr Sys allows waterflow and supervisory monitoring on
same module
Comb. Monitor allows waterflow and supervisory monitoring on
same module
