Notifier BACnet GW-3 User Manual

NOTIFIER® BACnet Gateway-3 Features System Architecture
12 BACnet Gateway-3 Installation and Operation Manual - P/N: 53372:Rev: A 5/6/09
Figure 1.2 Notifier System Example 1- A Single NFN Network
FACP FACP
NFN Network
IP Network
BACnet GW-3
FACP
BACnet/IP Client with Workstation Front End
BACnet/IP Client with Workstation Front End
HS-NCM W/SF/MF
or
NCM W/F

Notifier BACnet GW-3 Specifications

General

Brand	Notifier
Model	BACnet GW-3
Category	Gateway
Language	English
