Notifier BACnet GW-3 User Manual

15BACnet Gateway-3 Installation and Operation Manual - P/N: 53372:Rev: A 5/6/09
Section 2 BACnet GW-3 Embedded Installation
2.1 Required Equipment
The BACnet GW-3 requires the following:
BACnet GW-3 Assembly
The following are shipped with the BACnet GW-3:
• BACnet GW-3 board
• PNET-1 surge suppressor (P/N PNET-1)
• NUP to NUP Cable (P/N 75556)—used to connect the BACnet GW-3 board to an HS-NCM-
W/SF/MF boardl or NCM-W/F board and supported panel
• USB Cable (P/N 75665)—used to connect the BACnet GW-3 board to an HS-NCM-W/SF/MF
boardl
• Wire Leads to NUP Network Communications Module power cable (P/N 75583)
Network Components
• RJ45 to RJ45 standard Ethernet network cable—customer’s internet or intranet connection to
BACnet GW-3
• Workstation v3.11 or above (sold separately)
• NFN network—version 5.0 or above (sold separately)
• High Speed Network Communications Module: HS-NCM-W/SF/MF board—used to facilitate
network communication between the BACnet GW-3 and a High Speed NFN network (sold
separately) OR
• Network Communications Module: NCM-W/F board—used to facilitate network
communication between the BACnet GW-3 and an NFN network (sold separately).
Cabinet and Hardware (sold separately)
• CAB-3/CAB-4 series cabinet
• CHS-4L chassis
Customer Supplied Equipment
• A computer to run the BACNet Gateway Configuration Tool and configure the BACnet GW-3.
Contact Technical Support for software version compatibility.
NOTE: The BACnet GW-3 is for ancillary use only and does not increase the burglary grade of service
for the system.
NOTE: No HS-NCM-W/SF/MF board or NCM-W/F board is required when the BACnet GW-3
connects directly to a supported NOTIFIER® panel or annunciator when it is a standalone panel
or annunciator. Refer to “Panel Communication Connection Table” on page 47 for a list of
supported panels.

Notifier BACnet GW-3 Specifications

General

Brand	Notifier
Model	BACnet GW-3
Category	Gateway
Language	English
