Notifier BACnet GW-3 User Manual

BACnet GW-3 Installation Overview BACnet GW-3 Embedded Installation
17BACnet Gateway-3 Installation and Operation Manual - P/N: 53372:Rev: A 5/6/09
2.2.2 BACnet GW-3 Board Layout
Figure 2.2 BACnet GW-3 Board
Ethernet Connector
(J8)
NUP A Serial Data
Connector (J6)
TB6:
NO
Com
NC
TB1:
-24 V Out
+24 V Out
-24 V In
+24 V In
USB “B” Device (J14)USB “A” Host (J13)
Mounting Hole with
Surrounding
Grounding Area (5
locations)
Not Used
not used (J7)

Notifier BACnet GW-3 Specifications

General

Brand	Notifier
Model	BACnet GW-3
Category	Gateway
Language	English
