NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT
14
Mounting
To mount the E-STS-O, two brackets have been provided that are each secured with a screw (provided).
Install each bracket with the raised ridge
towards the front of the sensor, so that the
bracket sits flat and squarely against
the sensor case.
Do not over tighten screws or stripping of
the case will occur.
Brackets and screws
ready to install.
E-STS-IP67 includes two metal
brackets instead of plastic, but attach
to the 4 holes in the rear of the case.
As with the E-STS-O, be careful
not
to over tighten the screws provided or
stripping of the case will occur.
Sensor ready to mount
Brackets and screws installed.
