Concentric Venting Options
Figure 4-2(a) Figure 4-2(b)
Concentric Side Wall Termination (Optional Kit) Concentric Roof Termination (Optional Kit)
T
wo-Pi
p
e
V
entin
g
O
p
tions
Figure 4-3(a) Figure 4-3(b)
Two-Pipe Side Wall Termination Two-Pipe Roof Termination
