NTI TRINITY Ts80 - Parts List: Ts80 Model

Ts Series Installation and Operation Instructions │Trinity Ts
71
Table 17-1 Parts List: Ts80 Model
Item Part # Description
1
84248
Premix burner
2 82761 Premix Burner Gasket
3 82771 Extended Air Tube
4 82766 Blower Gasket
5 82052 EBM Blower RG130
6 82054-2 CVI Venturi Gasket or O-ring
7 83205 CVI Venturi 003
8 83216 CVI 3.40mm Orifice #45.900.444.120B (field installed on LP converted units)
9 83206 Gasket
10 82054 Gas Valve (CVI) VK8115F1134B (Valve Only)
11 83870 Ignition Electrode, Dual – c/w gasket
12 82774 Flame Probe Gasket
13 82600 Gas Valve Regulator Vent Adapter
14 83883 CVI Gas Valve Inlet O-ring Gasket
15 82065 Gas Valve (CV1) 1/2" NPT elbow #45.900.400-132B
16 83606 Sensor, Supply, Tasseron, Dual
17 83218 Switch, Water Pressure, 1/4" NPT
18 83462 Street Tee, Brass, 1/4"
19 83007 1/4"x 1/8" Bushing, Brass
20 82539 Automatic Air Vent 1/8"
21 83608 Sensor, Flue, Tasseron, Dual
22 82765 Composite Flue Outlet Gasket
23 82763 Composite Flue Box
24 82764 Trinity Flue Box to Heat Exchanger Gasket
25 83605 Sensor, Return, Tasseron, Single
26 83706 Plug, Brass, 1/4" NPT
27 84021 Heat Exchanger-ASME
28 83042 Y-Drain Fitting 5/8", White
29 83721 Tee, PVC, 1/2", Sch.40, White
30 83720 Elbow, Street, PVC, 1/2", Sch.40, White
31 83715 Condensate Drain Tube
32 83112 Trinity Divider Plate Insulation c/w Washer & Screw
33 82770 Burner Door Viton Gasket
34 82769 Burner Door Ceramic Disc
35 82767 Cast Alum Burner Door
36 82762 Flame Rod
37 82099 1-1/2" MJ Coupling
38 84235 Air Metering Assembly
39 84170 Flue Outlet Adapter
40 84215 Coupling, Rubber , 3" x 1.5”, Fernco
41 84236 Wall Mounting Bracket, Top
42 84239 Air Switch Support Bracket
43 82662 Air Switch Huba 604.E021180 set @ .15" w.c.
44 84238 Display Mounting Bracket
45 82250 Snap Bushing, 1”
46 84237 Wall Mounting Bracket, Bottom
47 84214 Grommet, Diaphragm, 1/2”
48 84095 Dome Plug, 7/8”
49 83590 ICP Honeywell Segment Display
50 83140 Spark Igniter Cable, 21”
51 83190 Transformer, 24V, 40VA
52 83589 Controller
