Trinity Ts │Installation and Operation Instructions Ts Series
72
Item Part # Description
53 84241 Control Panel Cover
54 84242 Control Panel Base
55 84206 Terminal, Barrier Double Row, Line/Low Voltage
56 83517 Fuse, Matrix/Lx/Ts, 2 Amp, Plug Style
57 84192 Fuse Holder, Panel Mount, 20 Amp at 250VAC Max
58 83837 Fuse, Littelfuse 7A, 250VAC, Fast Blow
59 81027-1 Outdoor Sensor, 10K
60 83505 Grommet, Vinyl, 7/8” OD
61 53044 Snap Bushing, ½”
62 83927 Snap Bushing, 7/8”
63 84246 Front Cover
64 84244 Right Side
65 84243 Left Side
66 84245 Top
