Trinity Ts │Installation and Operation Instructions Ts Series
14
Labeling and Identification – Two Pipe Side Wall Labeling and Identification – Optional Kit
Figure 4-6 Figure 4-7
Two-Pipe Side Wall Termination Concentric Vent Termination Kit
Labeling and Identification – Low Profile Termination Kit
Figure 4-8
Low Profile Termination Kit
Warning Plate
Exhaust
Vent
Vent
Screen
V
ent Screen
Insert vent
screen into
socket joint of
termination
elbow. Secure
by cementing
a short piece
of venting into
the socket.
Venting
Vent
Screen
Gas Vent Directly Below
Keep Free of Obstructions
Combustion
Ai
r
-Inlet
Venting
End Cap
Vent Screen
Exhaust Vent
Air Inlet Pipe
Concentric
V
ent
Vent screen included
with kit as shown.
Fully Assembled
and Installed
A
i
r
-Inlet
Piping
Exhaust
Venting
A
pproved Orientation
Base
Cap
Low Profile Termination Kit
The vent /air-inlet pipes are field
supplied. Vent screens are build
in. Major components provided in
Low Profile Kit include: base, cap,
s.s. screws, and plastic anchors.
