Vmax I&O Manual │General Venting
15
Termination Options – Direct Vent Installation
The venting system of the VM110 and VM110P may be terminated using field supplied piping to construct a
“Two-Pipe” termination, see Figures 4-4(a), 4-5(a), 4-5(d), 4-6(a), 4-7(a) and 4-7(d); alternatively the venting
may be terminated using a factory kit selected from Table 4-4.
Venting Options - Due to potential moisture loading (build-up) along the exterior wall,
sidewall venting may not be the preferred venting option (see Figures 4-5 and 4-7).
The vent for this appliance shall not terminate over public walkways; or near soffit vents
or crawl space vents or other area where condensate of vapor could create a nuisance or
hazard or cause property damage; or where condensate or vapor could cause damage or
could be detrimental to the operation of regulators, relief valves, or other equipment.
Optional Termination Kits – Direct Vent Installation
Kits certified with the Vmax VM110 & VM110P are listed in Table 4-4 and available from IPEX, DuraVent,
Centrotherm and/or NTI. For more information on System 636 Vent Kits or wholesaler locations contact IPEX
directly USA: 1-800-463-9572 or www.IPEXamerica.com │ CAN: 1-866-473-9462 or www.ipexinc.com. For
more information on PolyPro Vent Kits or wholesaler locations contact DuraVent directly 1-800-835-4429 or
www.duravent.com. For more information on InnoFlue Vent Kits or wholesaler locations contact Centrotherm
directly at 1-877-434-3432 or www.centrotherm.us.com.
Table 4-4 Optional Vent Termination Kits
Description
Vent
Size
Supplier P/N
Figure
Vent Material
Compatibility
Vent Option
Roof
Wall
IPEX Low Profile
(Montage affleurant)
7
2”
196984
4-4(b), 4-6(c)
PVC/CPVC
7


3”
196985 (NTI P/N 84357)
IPEX Concentric
(Mur / toit)
5,6,7
2”
196005
4-4(c), 4-5(c),
4-6(b), 4-7(b)


3”
196116 (NTI P/N 82666)
197009
DuraVent - PolyPro
Concentric (mur)
2”
2PPS-HK
4-4(c), 4-6(d)
PVC/CPVC/PP


3”
3PPS-HK
DuraVent - PolyPro
Concentric (toit)
2”
2PPS-VK
4-5(c), 4-7(c)


3”
3PPS-VK
Centrotherm – InnoFlue
(Flush Mount)
2”
ISLPT0202
4-4(b), 4-6(c)


3”
ISLPT0303
Centrotherm – InnoFlue
Concentric (Wall)
8
2”
ICWS2413 & ICTC0224
4-4(c), 4-6(d)


3”
ICWS3513 & ICTC0335
ICWT352 & ICTC0335
Centrotherm – InnoFlue
Concentric (Roof)
8
2”
ICRT2439 & ICTC0224
4-5(c), 4-7(c)


3”
ICRT3539 & ICTC0335
Notes:
1
Instructions included with termination kits contain detailed assembly and installation instructions.
2
All factory termination kits are ULC S636 approved.
3
Clearance requirements in this manual supersede those of the instructions included with the vent terminal.
4
Piping MUST be secured to the vent terminal during installation.
5
IPEX Concentric Terminal MUST be cemented together and to the vent pipes during installation.
6
Vent Screens provided with boiler may be used with the IPEX Concentric Vent Kits; otherwise use IPEX vent screens
(2 in. vent screen P/N 196050; 3 in. vent screen P/N 196051 – each sold separately).
7
IPEX Low Profile and Concentric kits (excluding P/N 197009) are constructed out of ULC S636 approved PVC; check
with your local authority for the acceptance of PVC as a venting material prior to use.
8
Centrotherm Concentric termination kits must use the applicable “Twin pipe to concentric adapter,” part number
ICTC0224 or ICTC0335.
