NTI VM110 - VM110 P (Plus) Top; VM110 P (Plus) Bottom

Field Wiring │ Vmax I&O Manual
38
Figure 10-3(a) VM110P (Plus) Top
Figure 10-3(b) VM110P (Plus) Bottom
DHW Out
60 PSI Pressure Gauge
(factory supplied)
Condensate Drain
Boiler Outlet
Primary Loop
(factory supplied)
DHW Recirc.
Central Heat Inlet
Central Heat Outlet
DHW In
Gaskets
(factory supplied)
Boiler Inlet
150 PSI T&P Relief Valve
(factory supplied)
Auto Air Vent
(factory supplied)
3/4x1/2x3/4” Brass Tee
(factory supplied)
3/4” Brass Street Elbow
(factory supplied)
30 PSI Relief Valve
(factory supplied)
