Numatic TTB 1840 - Machine Set-Up; Fitting the brushes; Fitting the Floor Tool

22
ALWAYS ENSURE THAT THE BATTERY IS DISCONNECTED
BEFORE MAKING ANY ADJUSTMENTS
!
!
Fitting the brushes
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making tting and removal a simple process.
Slide the brush / pad under the brush deck (Fig.6).
Fit the brush / pad onto the Nulock drive chuck, twist to lock
the brush / pad in place (Fig.7).
Only use manufacturer supplied brushes.
This machine requires a 400mm brush or a 360mm pad.
Fitting the Floor Tool
The oor-tool has been designed for quick tting, allowing easy squeegee
blade replacement and a safety knock-off feature if the oor-tool gets snagged,
whilst in transit.
Swing the oor-tool carrier to the side of the machine
(Fig.8).
Secure to the carrier using the two
knobs tted to the oor-tool carrier
(Fig.9) - (Fig.9a).
Do not over tighten the retaining
knobs.
Safety gloves are recommended for the changing of used brushes.
Note:
It is easier to t the oor-tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.
Machine Set-Up
6
7
8
9
9a
