28
! !
Moving the machine
CAUTION
When moving or lifting the TTB 1840, follow the national safety guidelines on lifting.
! !
When the bottom tank (clean water) is full the machine can be tilted to a
maximum of 45
0
(Fig.17).
When the top tank (waste water) is full the machine can be tilted to a
maximum of 10
0
for transporting to dumping area (Fig.18).
CAUTION
Ensure both tanks are empty and the battery has been removed before attempting to lift the machine.
Transport the machine by tilting back on to the main transit wheels (Fig.19).
Weight of empty machine (Fig.20).
Without the battery pack:- 38.5Kg (85 lbs).
Battery pack weight:- 13.5Kg (30 lbs).
Complete machine :- 52Kg (115 lbs)
Machine Set-Up
