Numatic TTB 1840 - Floor Tool Blade Replacement

38
To change the oor-tool, rstly swing the oor-tool clear of the machine (Fig.41).
Unscrew the four knobs securing the blade holder (Fig.43).
Remove the blade holder (Fig.44).
Replace the Squeegee blades using (606261) replacement blade set (Fig.45),
tting the blades on to the moulded location lugs.
Ret the blade holder, retain using the two outer knobs (Fig.46).
Retting the Floor Tool Blades
Ensure the slotted blade goes to the front of the oor-tool (Fig.47).
Ret the oor-tool using the two central knobs to the
oor-tool. Refer to Page 9 for tting instructions.
1. Floor-tool main body
2. Blade carrier
3. Rear blade
4. Front blade (slotted)
5. Retaining Knobs x 4
1
2
3
5
4
Note:
The blades are designed to be reversible,
thus extending their useful working life.
Use Genuine NUMATIC spare parts.
use Replacement Blade Set (606261)
! !
ALWAYS ENSURE THAT THE BATTERY IS DISCONNECTED
PRIOR TO ANY MAINTENANCE
Changing the Floor-tool Blades
Undo the two oor-tool retaining knobs (Fig.42).
41
42
43
44
45
46
47
