Numatic TTB 1840 - Index; Machine Overview

4
10
12
13
14
15
16
17
18
19
20
21
11
1. Operator control panel ( see page 4 ) 12. Vacuum hose
2. Triggers 13. Separator
3. Waste-water tank 14. Clean-water ller cap
4. Clean-water tank 15. Clean-water level indicator
5. Brush deck 16. Clean-water tank ll point
6. Squeegee blades 17. On / Off switch
7. Floor-tool retaining knobs 18. Battery connector
8. Clean-water On / Off tap 19. Top tank (waste water) drainage hose
9. Clean-water emptying cap 20. Battery
10. Rear moving wheels 21. Spare / replacement battery
11. Floor-tool vacuum hose
