Numatic TTB 1840 - Control Panel Overview

6
9
10
11
11
Control Panel Overview
1 2 3 4
6
7
5
8
1 Battery Charge Level Meter 7 Mode Select Button
2 Hi / Lo Indicator 8 Water Flow On / Off Button
3 Brush Operation / Load Indicator 9 Handle Position Lever
4 Vacuum Indicator 10 On / Off Switch
5 Water Flow Indicator 11 Triggers
6 Hi / Lo Button
For full instructions on control panel set up and use, see machine operation set-up page 14.
