Nuova Simonelli TALENTO Service Manual

Edition 02 to 12/2013
8.6
SERVICE MANUAL
8IFO SFGJUUJOH UIF QBSUT UIF FOHJOFFS XJMM OFFE
to:
1 Screw on the top grinder completely until it
touches and than turn it quarter a turn back.
2 3FGJUUIFBEKVTUNFOUTDSFX
3 Secure it to grinder and reassemble the
whole unit.
4 6TF UIF SFMFWBOU TDSFX UP BEKVTU HSJOEJOH
fineness to obtain the desired coffee quality.
8.3 VENTILATION SYSTEM
The service engineer will needs to:
1 Switched off the machine.
2 Remove the ground drawer.
3 Turn the key anticlockwise.
4 Open the front panel.
To remove the coffee containers:
1 Block the two tabs closing the container.
2 Remove the container.
3 Remove the four phillips head screw on the
top panel.
4 Disconnect the wiring.
1/4
0
1
Fig. 15
4
A
Fig. 16
3
2
1
4
Fig. 17
A
B
Fig. 18
